POW-HVM6.2M-48V - PowMr 6200W DC 48V Solar Inverter Pure Sinus Hybrid Inverter with 120A MPPT Charger
POW-HVM6.2M-48V - PowMr 6200W DC 48V Solar Inverter Pure Sinus Hybrid Inverter with 120A MPPT Charger
Couldn't load pickup availability
Free Shipping: 9-15 days to arrive.
Express Delivery: 5-8 days to arrive.
Warehouse: China/USA/Europe, Can delivery to all countries, tax included.
Free shipping & User guarantee
Free shipping & User guarantee
- Free Shipping：Ships within 3days, arrives within 9-15 days
- Paid Express: Ships within 2days,arrives within 5-8 days
- Money back guarantee: Quality problems, return and exchange within 30 days
- 12-month warranty, long-term after-sales service
- No need to register account, Order tracking url will send to your email
- More FAQ:FAQ
Brand: PowMr
Lithium Battery Activation: Active Lithium Batteries
Battery Voltage: 48V
Battery Type: Lifepo4 Batteries, Lithium Batteries, Flooded Batteries, Gel Batteries, Lead-acid Batteries, AGM Batteries
Phase: Single Phase
AC output: 230Vac±5%
Rated Load Power: 6200w
PV Terminal Charging Mode: build-in MPPT Solar Charge Controller
PowMr 6200W DC48V Solar Inverter Pure Sinus Inverter with 120A Charger
| Item specifics | |||
| Condition: | new | Brand: | PowMr |
| System configuration: | Hybrid Inverter | Inverter technology: | Hybrid |
| Application: | home/garden | Charge mode: | MPPT (Maximum Power Point Tracking) |
| Particularities: | LCD screen, LED display | Product Type: | charger/inverter |
| Tension: | DC48V | Model: | POW-HVM6.2M-48V |
| power source: | Solar | Color: | Black |
| Wattage: | 6200W | Perfomance: | 6200W |
| current type: | universal | current output: | MPPT 120A |
| Resistance Properties: | dustproof | Rated current: | MPPT 120A |
| Protective properties: | Overvoltage protection | Recommended environment: | Inside |
| Unit of measurement: | Unit | Maximum input voltage: | 500V |
| EAN: | Does not apply | ||
Please note:
● The delivery time on the product page is incorrect. To know the exact time, please contact us
● The buyer is responsible for the customs duties incurred at the destination and we will ship the package by FedEX, UPS, DHL
● The grid-tied feature requires a safety certificate and offers only a one-time purchase of over 800 units. Otherwise, it is an off-grid inverter machine
● If you need the off-grid function. Contact us for advice before placing an order
Features:
● 6200W pure sine wave inverter 48V DC to 230V AC built in 120A MPPT solar controller. It's a new All-in-One Hybrid Solar Inverter, Max PV power: 6500W; Max PV input VOC: 450V DC; Max PV charging current: 120A (MPPT controller to 48V battery).
● Solar 48V inverter charger suitable for 48V lead-acid, lithium, user battery. Schedule the charging and discharging time of the inverter flexibly, hybrid inverters have intelligent battery charging system, overload, overtemperature and short circuit protection, cold start function, optimized battery performance are allowed to extend battery life.
● LCD real-time display of charging parameters, configurable house voltage range, charging current, AC and solar charging priority, acceptable input voltage via LCD settings, the perfect solution for your solar system.
● The solar inverter has four input modes, namely solar priority/grid priority/solar and grid priority/solar only, to meet the needs of different applications.
● Wide range of applications: designed and can be used for all low-power appliances in homes, caravans, boats, TVs, lighting, computers and even inverter refrigerators.
PowMr 6200W Inverter DataSheet
Please read the specification carefully before install
| ODEL | POW-HVM6.2M-48V | |
| Phase | 1-phase | |
| Maximum PV Input Power | 6000W | |
| Rated Output Power | 6000W | |
| Maximum Charging Power | 6000W | |
| GRID-TIE OPERATION | ||
| PV Input(DC) | ||
| Nominal DC Voltage/Maximum DC Voltage | 360VDC/500VDC | |
| Start-up Voltage/initial Feeding Voltage | 120VDC | |
| MPPT Voltage Range | 90VDC~450VDC | |
| Number of MPPT Trackers/Maximum Input Current | 1/27A | |
| GRID OUTPUT(AC) | ||
| Nominal Output Voltage | 220/230/240VAC | |
| Output Voltage Range | 195.5-253VAC | |
| Nominal Output Current | 15.7A 26.1A | |
| Power Factor | >0.9 | |
| EFFICIENCY | ||
| Maximum Conversion Efficiency(DC/AC) | 97% | |
| OFF-GRID OPERATION | ||
| AC INPUT | ||
| AC Start-up Voltage/Anto Restart Voltage | 120-140VAC/180VAC | |
| Acceptable Input Voltage Range | 90-280VAC OR170-280VAC | |
| Maximum AC Input Current | 40A | |
| PV Input(DC) | ||
| Nominal DC Voltage | 500VDC | |
| MPPT Voltage Range | 90VDC-450VDC | |
| Number of MPPT Trackers/Maximum Input Current | 1/27A | |
| BATTERY MODE OUTPUT(AC) | ||
| Nominal Output Voltage | 24VDC 48VDC | |
| Output Waveform | Pure sine wave | |
| Efficiency(DC to AC) | 94% | |
| HYBRID OPERATION | ||
| PV INPUT(DC) | ||
| Nominal DC Voltage/Maximum DC Voltage | 360VDC/500VDC | |
| Start-up Voltage/initial Feeding Voltage | 120VDC | |
| MPPT Voltage Range | 90VDC-450VDC | |
| Number of MPPT Trackers/Maximum Input Current | 1/27A | |
| GRID OUTPUT(AC) | ||
| Nominal Output Voltage | 220/230/240VAC | |
| Output Voltage Range | 195.5-253VAC | |
| Nominal Output Current | 15.7A 26.1 A | |
| AC INPUT | ||
| AC Start-up Voltage/Anto Restart Voltage | 120-140VAC/180VAC | |
| Acceptable Input Voltage Range | 90-280VAC or 170-280VAC | |
| Maximum AC Input Current | 40A | |
| BATTERY MODE OUTPUT(AC) | ||
| Nominal Output Voltage | 220/230/240VAC | |
| Efficiency (DC to AC) | 94% | |
| BATTERY & CHARGE | ||
| Nominal DC Voltage | 48VDC | |
| Maximum Solar Charging Current | 120A | |
| Maximum AC Charging Current | 80A | |
| Maximum Charging Current | 120A | |
| GENERAL | ||
| PHYSICAL | ||
| Dimension D *W *H | 420*310*120 | |
| Net Weight(kgs) | 13 | |
| INTERFACE | ||
| Communication Port | RS232/WIFI/BMS | |
| ENVIRONMENT | ||
| Humidity | 0-90% | |
| Operating Temperature | -10 to 50 °C | |
